P1BK (4-corner air suspension with electronic shock absorption control)
porsche 2023 (taycan 9j1-1) compressor air supply unit parts diagram

504-000 - Compressor Air supply unit

Porsche 2023 (Taycan 9J1-1) Compressor Air supply unit Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 1
                      MPN: 9J1616006D
                      AIR SUPPLY UNIT (COMPLETE)
                      from £1,129.01
                      from £1,129.01
                      AIR SUPPLY UNIT Genuine Porsche Part - New (to order)
                      # 2
                      MPN: 9J1616199
                      bracket for compressor
                      from £219.12
                      from £219.12
                      bracket for compressor Genuine Porsche Part - New (to order)
                      # 3
                      MPN: 9J1616645A
                      AIR LINE
                      from £117.04
                      from £117.04
                      AIR LINE Genuine Porsche Part - New (to order)
                      # 4
                      MPN: 9J1616591
                      RETAINER FOR CONTROL UNIT WITH FIXING PARTS
                      from £273.70
                      from £273.70
                      central control unit Genuine Porsche Part - New (to order)
                      # 5
                      MPN: 9J1616691
                      INTAKE HOSE WITH: AIR FILTER
                      from £112.08
                      from £112.08
                      1 SET OF FASTENING PARTS FOR COMPRESSOR Genuine Porsche Part - New (to order)
                      # 6
                      MPN: 971616056C
                      VALVE BLOCK FOR ADAPTIVE SUSPENSION
                      from £304.33
                      from £304.33
                      VALVE BLOCK FOR ADAPTIVE Genuine Porsche Part - New (to order)
                      # 7
                      MPN: N 90887703
                      HEXAGON FLANGE NUT, M6 SELF-LOCKING
                      from £1.15
                      from £1.15
                      HEXAGON FLANGE NUT, Genuine Porsche Part - New (to order)
                      PREV.TORQUE TYPE M6 Genuine Lamborghini - New In stock
                      # 8
                      MPN: PAF008866
                      THREADED PIN M6X21
                      from £1.09
                      from £1.09
                      THREADED PIN Genuine Porsche Part - New (to order)
                      # 9
                      MPN: 95535950900
                      LINE HOLDER
                      from £4.13
                      from £4.13
                      LINE HOLDER Genuine Porsche Part - New (to order)
                      # 10
                      MPN: PAB907778
                      CONTROL UNIT FOR ADAPTIVE SUSPENSION
                      from £287.26
                      from £287.26
                      ELECTRONIC CONTROL UNIT FOR Genuine Porsche Part - New (to order)
