porsche 2025 (taycan 9j1-2) wing parts diagram

801-400 - WING

Porsche 2025 (Taycan 9J1-2) Wing Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                            #
                            Part number
                            Description
                            Price
                            # 1
                            MPN: 9J1821101GYGRV
                            WING LEFT - PRIMED
                            P2W9 (Electric charging door)
                            from £464.49
                            from £464.49
                            # 1
                            MPN: 9J1821102GYGRV
                            WING RIGHT - PRIMED
                            P2W9 (Electric charging door)
                            from £464.49
                            from £464.49
                            # 1
                            MPN: 9J1 821 101 EY GRV
                            WING LEFT - PRIMED
                            P2W5 (Fuel filler cap without retaining strap) | PL0R (Right-hand drive) | PE4E (Silver Edition)
                            # 1
                            MPN: 9J1 821 102 EY GRV
                            WING RIGHT - PRIMED
                            P2W5 (Fuel filler cap without retaining strap) | PL0L (Left-hand drive)
                            # 1
                            MPN: 9J1 821 101 FY GRV
                            WING LEFT - PRIMED
                            P2W5 (Fuel filler cap without retaining strap) | PE4E (Silver Edition) | PL0L (Left-hand drive)
                            # 1
                            MPN: 9J1 821 102 FY GRV
                            WING RIGHT - PRIMED
                            P2W5 (Fuel filler cap without retaining strap) | PE4E (Silver Edition) | PL0R (Right-hand drive)
                            # 2
                            MPN: 9J1854521 G2X
                            COVERS LEFT WING - PRIMED
                            from £20.61
                            from £20.61
                            # 2
                            MPN: 9J1854522 G2X
                            COVERS RIGHT WING - PRIMED
                            from £20.61
                            from £20.61
                            # 2
                            MPN: 9J0854521
                            COVERS LEFT WITHOUT PRIMER REWORK
                            from £20.61
                            from £20.61
                            # 2
                            MPN: 9J0854521A
                            COVERS LEFT WITHOUT PRIMER REWORK
                            from £20.54
                            from £20.54
                            # 2
                            MPN: 9J0854522
                            COVERS RIGHT WITHOUT PRIMER REWORK
                            from £20.61
                            from £20.61
                            # 2
                            MPN: 9J0854522A
                            COVERS RIGHT WITHOUT PRIMER REWORK
                            from £20.54
                            from £20.54
                            # 3
                            MPN: 9J1805373 YGRV
                            CONSOLE LEFT FOR WING - PRIMED
                            from £50.39
                            from £50.39
                            # 3
                            MPN: 9J1805374 YGRV
                            CONSOLE RIGHT FOR WING - PRIMED
                            from £50.39
                            from £50.39
                            # 4
                            MPN: 9J1801869 YGRV
                            DEFORMATION ELEMENT LEFT WING - PRIMED
                            from £16.04
                            from £16.04
                            # 4
                            MPN: 9J1801870 YGRV
                            DEFORMATION ELEMENT RIGHT WING - PRIMED
                            from £16.04
                            from £16.04
                            # 5
                            MPN: 9J1854945
                            RETAINER FOR TRIM LEFT WING
                            from £10.88
                            from £10.88
                            # 5
                            MPN: 9J1854946
                            RETAINER FOR TRIM RIGHT WING
                            from £10.88
                            from £10.88
                            # 6
                            MPN: 9J1854777C OK1
                            trim for a-pillar left - Matt black
                            from £57.28
                            from £57.28
                            # 6
                            MPN: 9J1854778C OK1
                            trim for a-pillar right - Matt black
                            from £57.28
                            from £57.28
                            # 7
                            MPN: PAD809963
                            AIR GUIDE LEFT
                            from £13.98
                            from £13.98
                            # 7
                            MPN: PAD809964
                            AIR GUIDE RIGHT
                            from £13.98
                            from £13.98
                            # 8
                            MPN: N 10321003
                            BOLT, HEXAGON HEAD M6X16 SELF-LOCKING
                            from £0.59
                            from £0.59
                            # 9
                            MPN: N 91242501
                            CLAMPING NUT 4.8X22X18
                            from £0.87
                            from £0.87
                            This part replaces part number 99950730902 - and 2 more. Click to view details
                            # 10
                            MPN: WHT007698
                            Hexagon socket head panel bolt 4,8X16
                            from £0.61
                            from £0.61
                            # 11
                            MPN: WHT004935
                            EXPANDING NUT TP5X15.5
                            from £0.59
                            from £0.59
                            # 12
                            MPN: WHT004935
                            EXPANDING NUT TP5X15.5
                            from £0.59
                            from £0.59
                            # 13
                            MPN: N 90974701
                            HEXAGON SOCKET HEAD PANEL BOLT TP5X16
                            from £0.54
                            from £0.54
                            # 14
                            MPN: PAF038549
                            Spreader rivet 8X12
                            from £0.47
                            from £0.47
                            This part replaces part number N 0385494
                            # 15
                            MPN: PAF 012 197
                            DISC (DIAMOND COATED) 6,5X18X0.1
                            PB2H (Part set, complying with vehicle type for South Korea, various parts)
