porsche 2025 (taycan 9j1-2) air conditioning refrigerant line parts diagram

814-400 - Air conditioning Refrigerant line

Porsche 2025 (Taycan 9J1-2) Air conditioning Refrigerant line Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                        #
                                        Part number
                                        Description
                                        Key
                                        Price
                                        # 1
                                        MPN: 9J1820033A
                                        REFRIGERANT LINE
                                        from £80.97
                                        from £80.97
                                        REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                        # 2
                                        MPN: PAD 820 729
                                        REFRIGERANT LINE
                                        REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                        # 3
                                        MPN: PAD 820 741
                                        REFRIGERANT LINE NON-RETURN VALVE
                                        REFRIGERANT LINE NON-RETURN VALVE Genuine Porsche Part - New (to order)
                                        # 4
                                        MPN: PAD820730
                                        REFRIGERANT LINE
                                        from £80.97
                                        from £80.97
                                        REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                        # 5
                                        MPN: 9J1820739B
                                        REFRIGERANT LINE
                                        from £80.97
                                        from £80.97
                                        REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                        # 6
                                        MPN: PAD820249B
                                        PRESSURE LINE
                                        from £166.64
                                        from £166.64
                                        PRESSURE LINE Genuine Porsche Part - New (to order)
                                        # 7
                                        MPN: PAD816198C
                                        SUCTION LINE
                                        from £197.60
                                        from £197.60
                                        SUCTION LINE Genuine Porsche Part - New (to order)
                                        # 8
                                        MPN: 9A781658100
                                        COVER VALVE
                                        from £4.79
                                        from £4.79
                                        COVER Genuine Porsche Part - New (to order)
                                        # 9
                                        MPN: PAB959603
                                        PRESSURE SENSOR AIR CONDITIONING
                                        from £97.54
                                        from £97.54
                                        This part replaces part number 9A795960300
                                        PRESSURE SENSOR Genuine Porsche Part - New (to order)
                                        # 10
                                        MPN: PAB959603B
                                        PRESSURE & TEMPERATURE SENSOR
                                        from £97.49
                                        from £97.49
                                        PRESSURE & TEMPERATURE SENSOR Genuine Porsche Part - New (to order)
                                        # 11
                                        MPN: 95557374901
                                        O-RING 11X2,5
                                        from £4.36
                                        from £4.36
                                        O-RING Genuine Porsche Part - New (to order)
                                        # 12
                                        MPN: 95557374902
                                        O-RING 13,7X2,5
                                        from £4.16
                                        from £4.16
                                        O-RING Genuine Porsche Part - New (to order)
                                        # 13
                                        MPN: 9A757374903
                                        O-RING 16,25X2,5
                                        from £3.74
                                        from £3.74
                                        O-RING Genuine Porsche Part - New (to order)
                                        # 14
                                        MPN: 95557374903
                                        O-RING 23,8X2,4
                                        from £3.72
                                        from £3.72
                                        O-RING Genuine Porsche Part - New (to order)
                                        # 15
                                        MPN: N 10632102
                                        OVAL HEXAGON SOCKET HEAD BOLT M6X25
                                        from £0.72
                                        from £0.72
                                        OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                                        HEXALOBULAR SOCKETM6X25 Genuine Lamborghini - New (to order)
                                        # 16
                                        MPN: N 10720901
                                        SOCKET HEAD BOLT WITH INNER M8X28 MULTIPOINT HEAD (KOMBI)
                                        from £1.15
                                        from £1.15
                                        BOLT, WITH POLYGON SOCKET HD. Genuine Porsche Part - New (to order)
                                        12-POINT SOCKET Genuine Lamborghini - New (to order)
                                        # 17
                                        MPN: PAF107388
                                        TORX M6X35 LENS FLANGE SCREW
                                        from £1.62
                                        from £1.62
                                        SCREW Genuine Porsche Part - New (to order)
                                        # 18
                                        MPN: N 10700201
                                        HEXAGON SOCKET HEAD BOLT M6X22
                                        from £1.15
                                        from £1.15
                                        HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                                        HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
                                        # 19
                                        MPN: 9J1820137
                                        BRACKET
                                        from £2.50
                                        from £2.50
                                        BRACKET Genuine Porsche Part - New (to order)
