porsche 2026 (taycan 9j1-2) coolant pump parts diagram

155-000 - COOLANT PUMP

Porsche 2026 (Taycan 9J1-2) Coolant pump Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                    #
                                    Part number
                                    Description
                                    Price
                                    # 1
                                    MPN: 9J1965567H
                                    Coolant pump P1,P2
                                    from £221.80
                                    from £221.80
                                    # 2
                                    MPN: PAD121077
                                    BRACKET
                                    from £8.74
                                    from £8.74
                                    # 3
                                    MPN: 9J1965567G
                                    Coolant pump P5
                                    from £219.40
                                    from £219.40
                                    # 4
                                    MPN: PAD121078
                                    BRACKET
                                    from £8.74
                                    from £8.74
                                    # 5
                                    MPN: N 10721401
                                    oval hd. self-tapp fitt. screw 6X16
                                    from £0.47
                                    from £0.47
                                    # 6
                                    MPN: PAD 133 567 A
                                    RUBBER BUSH P2
                                    # 7
                                    MPN: PAD 133 567
                                    RUBBER BUSH P5
                                    # 8
                                    MPN: PAF104422
                                    Hexagon socket oval head bolt M6X40 (combi)
                                    from £1.82
                                    from £1.82
                                    # 9
                                    MPN: N 91096801
                                    Hexagon socket flat M6X20 head bolt
                                    from £0.87
                                    from £0.87
                                    # 10
                                    MPN: 9J1965543
                                    BRACKET
                                    from £39.46
                                    from £39.46
                                    # 11
                                    MPN: 9J1965544
                                    BRACKET
                                    from £8.27
                                    from £8.27
                                    # 12
                                    MPN: N 91096701
                                    OVAL HEXAGON SOCKET HEAD BOLT M6X16
                                    from £0.78
                                    from £0.78
                                    # 13
                                    MPN: 9J1820495
                                    BRACKET
                                    from £12.45
                                    from £12.45
                                    # 14
                                    MPN: 9A7129669
                                    GROMMET
                                    from £3.46
                                    from £3.46
                                    # 15
                                    MPN: 9J1820409
                                    RUBBER BUSH
                                    from £0.90
                                    from £0.90
                                    # 16
                                    MPN: PAD820196
                                    BRACKET P2
                                    from £9.11
                                    from £9.11
                                    # 17
                                    MPN: PAD816770
                                    BRACKET
                                    P1X2 (Rear-wheel drive)
                                    from £39.70
                                    from £39.70
                                    # 17
                                    MPN: PAD816770A
                                    BRACKET
                                    P1X1 (Four-wheel drive)
                                    from £39.70
                                    from £39.70
                                    # 18
                                    MPN: N 10632003
                                    Oval socket head bolt M6X16 with hex drive
                                    from £0.47
                                    from £0.47
