porsche 2026 (taycan 9j1-2) drive cooling rear axle parts diagram

155-550 - Drive cooling Rear axle

Porsche 2026 (Taycan 9J1-2) Drive cooling Rear axle Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: PAD121109A
                Coolant hose feed
                PE0A (No special edition) | PE0W (Special edition)
                from £39.96
                from £39.96
                COOLANT HOSE Genuine Porsche Part - New (to order)
                # 1
                MPN: PAD121109
                Coolant hose feed
                PE0B (Black Edition) | PE4E (Silver Edition)
                from £39.96
                from £39.96
                COOLANT HOSE Genuine Porsche Part - New (to order)
                # 2
                MPN: 9J1121101
                COOLANT HOSE WITH RETURN QUICK RELEASE COUPLING
                from £36.32
                from £36.32
                COOLANT PIPE Genuine Porsche Part - New (to order)
                # 3
                MPN: PAD121177A
                COOLANT HOSE
                PE0A (No special edition) | PE0W (Special edition) | PE2B, PE8A (Turbo S)
                from £36.32
                from £36.32
                COOLANT HOSE Genuine Porsche Part - New (to order)
                # 3
                MPN: PAD121177
                COOLANT HOSE
                PE0B (Black Edition) | PE4E (Silver Edition)
                from £36.32
                from £36.32
                COOLANT HOSE Genuine Porsche Part - New (to order)
                # 4
                MPN: 9J1121178B
                Coolant hose Included Spacer ring
                from £36.32
                from £36.32
                COOLANT PIPE Genuine Porsche Part - New (to order)
                # 5
                MPN: 9J1121264
                BRACKET
                from £7.79
                from £7.79
                BRACKET Genuine Porsche Part - New (to order)
                # 6
                MPN: PAF100323
                SPREADER RIVET
                from £0.47
                from £0.47
                SPREADER RIVET Genuine Porsche Part - New (to order)
                # 7
                MPN: PAD121743A
                Coolant connection Bent
                from £11.64
                from £11.64
                COOLANT CONNECTION Genuine Porsche Part - New (to order)
                # 8
                -
                ** VERSION BEING PREPARED **
                # 9
                -
                HEAT EXCHANGER SEE ILLUSTRATION: 355-100
