P1P8 (Comfort suspension) | PL0L (Left-hand drive) | PL0R (Right-hand drive)
porsche 2026 (taycan 9j1-2) cross member support frame parts diagram

401-005 - Cross member Support frame

Porsche 2026 (Taycan 9J1-2) Cross member Support frame Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                              #
                                              Part number
                                              Description
                                              Key
                                              Price
                                              # 1
                                              MPN: PAD400048
                                              SUPPORT FRAME
                                              from £1,584.06
                                              from £1,584.06
                                              SUPPORT FRAME Genuine Porsche Part - New (to order)
                                              # 2
                                              MPN: N 91244301
                                              Hexagon collared bolt with M12X1.5X90 hexagon socket head (duo)
                                              from £3.55
                                              from £3.55
                                              HEX BOLT WITH TORX HEAD Genuine Porsche Part - New In stock
                                              # 3
                                              MPN: 9J1880101
                                              SUPPORT
                                              from £15.28
                                              from £15.28
                                              SUPPORT Genuine Porsche Part - New (to order)
                                              # 4
                                              MPN: PAF10063604
                                              HEXAGON BOLT
                                              from £1.41
                                              from £1.41
                                              SCREW, HEX. HD Genuine Porsche Part - New (to order)
                                              # 5
                                              MPN: 9J1407167C
                                              REINFORCEMENT LEFT
                                              from £40.99
                                              from £40.99
                                              REINFORCEMENT Genuine Porsche Part - New (to order)
                                              # 5
                                              MPN: 9J1407168C
                                              REINFORCEMENT RIGHT
                                              from £40.99
                                              from £40.99
                                              REINFORCEMENT Genuine Porsche Part - New (to order)
                                              # 6
                                              MPN: PAF10063604
                                              HEXAGON BOLT
                                              from £1.41
                                              from £1.41
                                              SCREW, HEX. HD Genuine Porsche Part - New (to order)
                                              # 7
                                              MPN: 9J1407129E
                                              REINFORCEMENT PLATE LEFT
                                              from £47.33
                                              from £47.33
                                              REINFORCEMENT PLATE Genuine Porsche Part - New (to order)
                                              # 8
                                              MPN: 9J1407130C
                                              REINFORCEMENT PLATE RIGHT
                                              from £47.33
                                              from £47.33
                                              REINFORCEMENT PLATE Genuine Porsche Part - New (to order)
                                              # 9
                                              MPN: N 91242501
                                              CLAMPING NUT ST4.8X22X18
                                              from £0.87
                                              from £0.87
                                              This part replaces part number 99950730902 - and 2 more. Click to view details
                                              CLAMPING NUT Genuine Porsche Part - New In stock
                                              SNAP NUT CLAMP ST4.8X22X18 Genuine Lamborghini - New In stock
                                              # 10
                                              MPN: N 91243701
                                              Hexagon collared bolt with M8X30 hexagon socket head (duo)
                                              from £0.95
                                              from £0.95
                                              HEX BOLT WITH TORX HEAD Genuine Porsche Part - New (to order)
                                              # 11
                                              MPN: PAD 407 129
                                              REINFORCEMENT PLATE REAR CENTER
                                              REINFORCEMENT PLATE REAR CENTER Genuine Porsche Part - New (to order)
                                              # 12
                                              MPN: N 91242501
                                              CLAMPING NUT ST4.8X22X18
                                              from £0.87
                                              from £0.87
                                              This part replaces part number 99950730902 - and 2 more. Click to view details
                                              CLAMPING NUT Genuine Porsche Part - New In stock
                                              SNAP NUT CLAMP ST4.8X22X18 Genuine Lamborghini - New In stock
                                              # 13
                                              MPN: N 91243701
                                              Hexagon collared bolt with M8X30 hexagon socket head (duo)
                                              from £0.95
                                              from £0.95
                                              HEX BOLT WITH TORX HEAD Genuine Porsche Part - New (to order)
                                              # 14
                                              MPN: PAF912450
                                              SOCKET HEAD COLLARED BOLT WITH M10X42 INNER MULTIPOINT HEAD
                                              from £2.77
                                              from £2.77
                                              SCREW Genuine Porsche Part - New (to order)
                                              # 15
                                              MPN: 9J1413366B
                                              LINK FOR STABILIZER LEFT
                                              PL0L (Left-hand drive)
                                              from £269.14
                                              from £269.14
                                              LINK FOR STABILIZER Genuine Porsche Part - New (to order)
                                              # 16
                                              MPN: PAD399111A
                                              Engine Mounting
                                              from £27.87
                                              from £27.87
                                              Engine Mounting Genuine Porsche Part - New (to order)
                                              # 17
                                              -
                                              LINK FOR STABILIZER LEFT LOWER PART SEE ILLUSTRATION, ITEM: 402-050,6
                                              PL0L (Left-hand drive)
                                              # 18
                                              MPN: 9J1413358B
                                              LINK FOR STABILIZER RIGHT
                                              PL0L (Left-hand drive)
                                              from £182.06
                                              from £182.06
                                              LINK FOR STABILIZER Genuine Porsche Part - New (to order)
                                              # 19
                                              MPN: 9J1 413 366 C
                                              LINK FOR STABILIZER RIGHT
                                              PL0R (Right-hand drive)
                                              LINK FOR STABILIZER RIGHT Genuine Porsche Part - New (to order)
                                              # 20
                                              -
                                              LINK FOR STABILIZER RIGHT LOWER PART SEE ILLUSTRATION, ITEM: 402-060,6
                                              # 21
                                              MPN: 9J1413357B
                                              LINK FOR STABILIZER LEFT
                                              PL0R (Right-hand drive)
                                              from £182.06
                                              from £182.06
                                              LINK FOR STABILIZER Genuine Porsche Part - New (to order)
                                              # 22
                                              MPN: N 10664503
                                              Hex collared bolt M8X45
                                              from £1.73
                                              from £1.73
                                              BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                              # 23
                                              MPN: N 10831701
                                              SCREW WITH INT. SERRATIONS M8X60
                                              from £1.78
                                              from £1.78
                                              SCREW WITH INT. SERRATIONS Genuine Porsche Part - New (to order)
                                              12-POINT SOCKET M8X60 Genuine Lamborghini - New (to order)
                                              # 24
                                              MPN: N 10435506
                                              Hexagon collar nut M8 self-locking
                                              from £1.26
                                              from £1.26
                                              SHOULDERED HEX. NUT, Genuine Porsche Part - New (to order)
                                              PREV.TORQUE TYPE M8 Genuine Lamborghini - New In stock
                                              # 25
                                              MPN: PAF911058
                                              SOCKET HEAD BOLT WITH INNER M8X110 MULTIPOINT HEAD (KOMBI)
                                              from £2.48
                                              from £2.48
                                              SCREW Genuine Porsche Part - New (to order)
                                              # 26
                                              MPN: 9J1399111E
                                              Engine Mounting
                                              from £53.76
                                              from £53.76
                                              Engine Mounting Genuine Porsche Part - New (to order)
                                              # 27
                                              MPN: N 10664503
                                              Hex collared bolt M8X45
                                              from £1.73
                                              from £1.73
                                              BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
