P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
porsche 2026 (taycan 9j1-2) alloy wheel 21 parts diagram

601-150 - Alloy wheel 21

Porsche 2026 (Taycan 9J1-2) Alloy wheel 21 Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Price
    # 1
    MPN: 9J1601025CA041
    ALLOY WHEEL LEFT FRONT 9,5 J X 21 ET 60 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 2 - BLACK
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,499.79
    from £1,499.79
    # 1
    MPN: 9J1601025CAJE1
    ALLOY WHEEL LEFT FRONT 9,5 J X 21 ET 60 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 2 - MATT BLACK
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,499.79
    from £1,499.79
    # 1
    MPN: 9J1601025CAQO1
    ALLOY WHEEL LEFT FRONT 9,5 J X 21 ET 60 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 2 - BLACK TURNED ALUMINIUM
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,633.11
    from £1,633.11
    # 2
    MPN: 9J1601147N 041
    WHEEL TRIM RINGS LEFT FRONT PLASTIC ALSO USE: 8X PAF 011 546 - BLACK
    P1NV (Wheel trims)
    from £35.10
    from £35.10
    # 2
    MPN: 9J1601147N I44
    WHEEL TRIM RINGS LEFT FRONT PLASTIC ALSO USE: 8X PAF 011 546 - RHODIUM GREY
    P1NB (Covers for wheel hubs/wheel bolts)
    from £54.61
    from £54.61
    # 2
    MPN: 9J1601147N JE1
    WHEEL TRIM RINGS LEFT FRONT PLASTIC ALSO USE: 8X PAF 011 546 - MATT BLACK
    P1NX (Wheel trims)
    from £54.61
    from £54.61
    # 2
    MPN: 9J1601147N OS8
    WHEEL TRIM RINGS LEFT FRONT PLASTIC ALSO USE: 8X PAF 011 546 - DARK SILVER
    P1NM (Trims for alloy wheels)
    from £54.61
    from £54.61
    # 2
    MPN: 9J1601147N OZ1
    WHEEL TRIM RINGS LEFT FRONT PLASTIC ALSO USE: 8X PAF 011 546 - NEODYME
    P1NI (Hub cap)
    from £54.61
    from £54.61
    # 2
    MPN: 9J1601147J O3G
    WHEEL TRIM RINGS LEFT FRONT CFK ALSO USE: PAF 011 546 - CARBON GLOSS BLACK
    P1NK (Wheel trims)
    from £366.59
    from £366.59
    # 3
    MPN: 9J1601025CB041
    ALLOY WHEEL RIGHT FRONT 9,5 J X 21 ET 60 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 4 - BLACK
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,499.79
    from £1,499.79
    # 3
    MPN: 9J1601025CBJE1
    ALLOY WHEEL RIGHT FRONT 9,5 J X 21 ET 60 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 4 - MATT BLACK
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,499.79
    from £1,499.79
    # 3
    MPN: 9J1601025CBQO1
    ALLOY WHEEL RIGHT FRONT 9,5 J X 21 ET 60 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 4 - BLACK TURNED ALUMINIUM
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,633.11
    from £1,633.11
    # 4
    MPN: 9J1601147Q 041
    WHEEL TRIM RINGS RIGHT FRONT PLASTIC ALSO USE: 15X PAF 011 546 - BLACK
    P1NV (Wheel trims)
    from £35.10
    from £35.10
    # 4
    MPN: 9J1601147Q I44
    WHEEL TRIM RINGS RIGHT FRONT PLASTIC ALSO USE: 15X PAF 011 546 - RHODIUM GREY
    P1NB (Covers for wheel hubs/wheel bolts)
    from £54.61
    from £54.61
    # 4
    MPN: 9J1601147Q JE1
    WHEEL TRIM RINGS RIGHT FRONT PLASTIC ALSO USE: 15X PAF 011 546 - MATT BLACK
    P1NX (Wheel trims)
    from £54.61
    from £54.61
    # 4
    MPN: 9J1601147Q OS8
    WHEEL TRIM RINGS RIGHT FRONT PLASTIC ALSO USE: 15X PAF 011 546 - DARK SILVER
    P1NM (Trims for alloy wheels)
    from £54.61
    from £54.61
    # 4
    MPN: 9J1601147Q OZ1
    WHEEL TRIM RINGS RIGHT FRONT PLASTIC ALSO USE: 15X PAF 011 546 - NEODYME
    P1NI (Hub cap)
    from £54.61
    from £54.61
    # 4
    MPN: 9J1601147L O3G
    WHEEL TRIM RINGS RIGHT FRONT CFK ALSO USE: 15X PAF 011 546 - CARBON GLOSS BLACK
    P1NK (Wheel trims)
    from £366.59
    from £366.59
    # 5
    MPN: 9J1601025CG041
    ALLOY WHEEL LEFT REAR 11,5 J X 21 ET 66 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 6 - BLACK
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,541.44
    from £1,541.44
    # 5
    MPN: 9J1601025CGJE1
    ALLOY WHEEL LEFT REAR 11,5 J X 21 ET 66 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 6 - MATT BLACK
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,541.44
    from £1,541.44
    # 5
    MPN: 9J1601025CGQO1
    ALLOY WHEEL LEFT REAR 11,5 J X 21 ET 66 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 6 - BLACK TURNED ALUMINIUM
    P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) | P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,674.77
    from £1,674.77
    # 6
    MPN: 9J1601147P 041
    WHEEL TRIM RINGS LEFT REAR PLASTIC ALSO USE: 15X PAF 011 546 - BLACK
    P1NV (Wheel trims)
    from £35.10
    from £35.10
    # 6
    MPN: 9J1601147P I44
    WHEEL TRIM RINGS LEFT REAR PLASTIC ALSO USE: 15X PAF 011 546 - RHODIUM GREY
    P1NB (Covers for wheel hubs/wheel bolts)
    from £54.61
    from £54.61
    # 6
    MPN: 9J1601147P JE1
    WHEEL TRIM RINGS LEFT REAR PLASTIC ALSO USE: 15X PAF 011 546 - MATT BLACK
    P1NX (Wheel trims)
    from £54.61
    from £54.61
    # 6
    MPN: 9J1601147P OS8
    WHEEL TRIM RINGS LEFT REAR PLASTIC ALSO USE: 15X PAF 011 546 - DARK SILVER
    P1NM (Trims for alloy wheels)
    from £54.61
    from £54.61
    # 6
    MPN: 9J1601147P OZ1
    WHEEL TRIM RINGS LEFT REAR PLASTIC ALSO USE: 15X PAF 011 546 - NEODYME
    P1NI (Hub cap)
    from £54.61
    from £54.61
    # 6
    MPN: 9J1601147K O3G
    WHEEL TRIM RINGS LEFT REAR CFK ALSO USE: 15X PAF 011 546 - CARBON GLOSS BLACK
    P1NK (Wheel trims)
    from £366.59
    from £366.59
    # 7
    MPN: 9J1601025CH041
    ALLOY WHEEL RIGHT REAR 11,5 J X 21 ET 66 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 8 - BLACK
    P64V.64W, P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64V (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,541.44
    from £1,541.44
    # 7
    MPN: 9J1601025CHJE1
    ALLOY WHEEL RIGHT REAR 11,5 J X 21 ET 66 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 8 - MATT BLACK
    P64V.64W, P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64W (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,541.44
    from £1,541.44
    # 7
    MPN: 9J1601025CHQO1
    ALLOY WHEEL RIGHT REAR 11,5 J X 21 ET 66 ASSOCIATED ITEM/ITEMS TO BE USED AS NECESSARY: 8 - BLACK TURNED ALUMINIUM
    P64V.64W, P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear) - P64X (Alloy wheels 9.5J x 21 in front, with 11.5J x 21 in rear)
    from £1,674.77
    from £1,674.77
    # 8
    MPN: 9J1601147R 041
    WHEEL TRIM RINGS RIGHT REAR PLASTIC ALSO USE: 15X PAF 011 546 - BLACK
    P1NV (Wheel trims)
    from £35.10
    from £35.10
    # 8
    MPN: 9J1601147R I44
    Wheel trim rings right rear plastic also use: 15X PAF 011 546 - Rhodium grey
    P1NB (Covers for wheel hubs/wheel bolts)
    from £54.61
    from £54.61
    # 8
    MPN: 9J1601147R JE1
    WHEEL TRIM RINGS RIGHT REAR PLASTIC ALSO USE: 15X PAF 011 546 - MATT BLACK
    P1NX (Wheel trims)
    from £54.61
    from £54.61
    # 8
    MPN: 9J1601147R OS8
    WHEEL TRIM RINGS RIGHT REAR PLASTIC ALSO USE: 15X PAF 011 546 - DARK SILVER
    P1NM (Trims for alloy wheels)
    from £54.61
    from £54.61
    # 8
    MPN: 9J1601147R OZ1
    WHEEL TRIM RINGS RIGHT REAR PLASTIC ALSO USE: 15X PAF 011 546 - NEODYME
    P1NI (Hub cap)
    from £54.61
    from £54.61
    # 8
    MPN: 9J1601147M O3G
    WHEEL TRIM RINGS RIGHT REAR CFK ALSO USE: 15X PAF 011 546 - CARBON GLOSS BLACK
    P1NK (Wheel trims)
    from £366.59
    from £366.59
    # 9
    MPN: PAF011546
    Socket head bolt with M5X10 hexagon socket head
    from £1.29
    from £1.29
