porsche 2026 (taycan 9j1-2) bumper carrier front crash reinforcement parts diagram

802-400 - Bumper carrier front Crash reinforcement

Porsche 2026 (Taycan 9J1-2) Bumper carrier front Crash reinforcement Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                    #
                                    Part number
                                    Description
                                    Key
                                    Price
                                    # 1
                                    MPN: 9J1805241C
                                    Cross Member Front
                                    from £332.93
                                    from £332.93
                                    CROSS MEMBER Genuine Porsche Part - New (to order)
                                    # 2
                                    MPN: 9J1807549AA
                                    PLASTIC FOAM STRIP FRONT
                                    from £47.88
                                    from £47.88
                                    PLASTIC FOAM STRIP Genuine Porsche Part - New (to order)
                                    # 2
                                    MPN: 9J1807549AB
                                    PLASTIC FOAM STRIP FRONT
                                    from £87.05
                                    from £87.05
                                    PLASTIC FOAM STRIP Genuine Porsche Part - New (to order)
                                    # 3
                                    MPN: 9J1807617A
                                    Support lower
                                    from £63.96
                                    from £63.96
                                    SUPPORT Genuine Porsche Part - New (to order)
                                    # 4
                                    MPN: 9J1805015A
                                    LOCK CARRIER
                                    from £156.51
                                    from £156.51
                                    LOCK CARRIER Genuine Porsche Part - New (to order)
                                    # 5
                                    MPN: 9J1805353B
                                    pull strap front
                                    from £71.66
                                    from £71.66
                                    PULL STRAP Genuine Porsche Part - New (to order)
                                    # 6
                                    MPN: 9J1805360A
                                    REINFORCEMENT FRONT LID LOCK
                                    from £20.48
                                    from £20.48
                                    REINFORCEMENT Genuine Porsche Part - New (to order)
                                    # 7
                                    MPN: 9J1805230
                                    SEAL
                                    from £2.59
                                    from £2.59
                                    SEAL Genuine Porsche Part - New (to order)
                                    # 8
                                    MPN: 9A700744300
                                    HEXAGON HEAD BOLT M10X40
                                    from £1.97
                                    from £1.97
                                    HEXAGON HEAD BOLT Genuine Porsche Part - New In stock
                                    # 9
                                    MPN: N 91247301
                                    INT. SERRATION FLANGE SCREW M8X50 (COMBI-INSTRUMENT)
                                    from £1.78
                                    from £1.78
                                    INT. SERRATION FLANGE SCREW Genuine Porsche Part - New (to order)
                                    12-POINT SOCKET M8X50-S30 Genuine Lamborghini - New (to order)
                                    # 10
                                    MPN: PAF108387
                                    HEX. HD. SELF-TAP BOLT (COMBI) M6X22
                                    from £1.45
                                    from £1.45
                                    HEX. HD. SELF-TAP BOLT (COMBI) Genuine Porsche Part - New (to order)
                                    # 11
                                    MPN: N 10725401
                                    HEXAGON SOCKET HEAD COLLARED M6X20 BOLT, THREAD FORMING
                                    from £0.80
                                    from £0.80
                                    HEXAGON SOCKET HEAD COLLARED Genuine Porsche Part - New In stock
                                    HEXALOBULAR SOCKETM6GFX20 Genuine Lamborghini - New (to order)
                                    # 12
                                    MPN: 9A7820535
                                    EXTERNAL TEMPERATURE SENSOR
                                    from £28.54
                                    from £28.54
                                    This part replaces part number 8Z0820535A
                                    EXTERNAL TEMPERATURE SENSOR Genuine Porsche Part - New (to order)
                                    # 13
                                    MPN: 9A700769800
                                    PANEL SCREW ST4.8X16-C
                                    from £0.78
                                    from £0.78
                                    This part replaces part number 99907323109 - and 2 more. Click to view details
                                    tapping screw Genuine Porsche Part - New In stock
                                    # 14
                                    MPN: N 90887703
                                    HEXAGON FLANGE NUT, M6 SELF-LOCKING
                                    from £1.15
                                    from £1.15
                                    HEXAGON FLANGE NUT, Genuine Porsche Part - New (to order)
                                    PREV.TORQUE TYPE M6 Genuine Lamborghini - New In stock
                                    # 15
                                    MPN: N 91079901
                                    Hexagon collar bolt with M6X20 socket head
                                    from £1.43
                                    from £1.43
                                    BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                    SCREW Genuine Lamborghini - New (to order)
                                    # 16
                                    MPN: PAF 911 397
                                    DOUBLE HEXAGON BUNCH SCREW M6X20-M6X16
                                    DOUBLE HEXAGON BUNCH SCREW M6X20-M6X16 Genuine Porsche Part - New (to order)
                                    # 17
                                    MPN: N 91242501
                                    CLAMPING NUT ST4.8X22X18
                                    from £0.87
                                    from £0.87
                                    This part replaces part number 99950730902 - and 2 more. Click to view details
                                    CLAMPING NUT Genuine Porsche Part - New In stock
                                    SNAP NUT CLAMP ST4.8X22X18 Genuine Lamborghini - New In stock
