026.2 - Front Suspension (726 to 1000)
Lamborghini Espada Front Suspension (726 to 1000) Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
-
You can click on a hotspot
in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
001
MPN:
008101408
BOLT
from
£18.58
from
£18.58
#
002
MPN:
008401411
WASHER
from
£6.53
from
£6.53
#
003
MPN:
008921411
FLAMBLOC
163039
from
£103.76
from
£103.76
#
004
MPN:
005109254
BRACCIO SUPERIORE
from
£138.60
from
£138.60
#
005
MPN:
008401413
WASHER
from
£0.58
from
£0.58
#
006
MPN:
008201406
NUT
from
£0.55
from
£0.55
#
007
MPN:
008400801
WASHER
Supersession
Supersession
#
008
MPN:
008200804
NUT
from
£0.67
from
£0.67
#
009
MPN:
005100961
UPPER BALL JOINT
from
£74.66
from
£74.66
#
010
MPN:
005100961
UPPER BALL JOINT
from
£74.66
from
£74.66
#
011
MPN:
008101609
BOLT
from
£105.81
from
£105.81
#
012
MPN:
008401612
WASHER
from
£6.43
from
£6.43
#
013
MPN:
008921601
BUSH
from
£45.94
from
£45.94
#
014
MPN:
005108251
PIATTELLO SUPERIORE
from
£75.00
from
£75.00
#
015
MPN:
005108252
PARATIA
from
£40.59
from
£40.59
#
016
MPN:
008201603
NUT
from
£2.25
from
£2.25
#
017
MPN:
008401611
WASHER
from
£8.84
from
£8.84
#
018
MPN:
005108253
Front Shock Absorbers
from
£485.07
from
£485.07
#
019
MPN:
005108250
SPRING
from
£363.15
from
£363.15
#
020
MPN:
005107590
BRACCIO INFERIORE SINISTRO
from
£126.50
from
£126.50
#
020
MPN:
005107591
BRACCIO INFERIORE DESTRO
from
£126.50
from
£126.50
#
021
MPN:
008820301
SPLIT PIN
from
£1.67
from
£1.67
#
022
MPN:
008401614
WASHER
from
£12.90
from
£12.90
#
023
MPN:
008201212
NUT
from
£1.23
from
£1.23
#
024
MPN:
008401304
WASHER
from
£1.67
from
£1.67
#
025
MPN:
005100555
LOWER BALL JOINT
from
£234.39
from
£234.39
#
026
MPN:
008101016
BOLT
from
£14.98
from
£14.98
#
027
MPN:
008101217
BOLT
from
£12.90
from
£12.90
#
028
MPN:
008401006
WASHER
from
£0.53
from
£0.53
#
029
MPN:
008201010
NUT
from
£0.87
from
£0.87
#
030
MPN:
008201007
NUT
from
£4.73
from
£4.73
#
031
MPN:
008701003
VITO
from
£10.87
from
£10.87
#
032
MPN:
008921801
ANTI ROLL BAR BUSH
18 mm diameter
from
£23.87
from
£23.87
#
033
MPN:
005101056
JUBILEE CLIP
from
£39.00
from
£39.00
#
034
MPN:
008922002
ANTI ROLL BAR BUSH
20 mm diameter
from
£36.02
from
£36.02
#
035
MPN:
005107594
BARRA DI TORSIONE
#
036
MPN:
005101047
JUBILEE CLIP
from
£68.41
from
£68.41
#
037
MPN:
008201006
NUT
from
£4.73
from
£4.73
